Structure for schedule table. More...
#include <ScheduleTableTypes.h>
Data Fields | |
| const TickType | finalDelay |
| Final delay of schedule table (applied after last expiry point. More... | |
| const uint8_t | numExpiryPoints |
| Length of expiryPointList. More... | |
| const struct scheduleTableExpiryPoint_s * | expiryPointList |
| List of expiry points. More... | |
| const CounterType | counter |
| Counter driving the schedule table. More... | |
| const bool | autoStart |
| If true the schedule table will be started at startup. More... | |
| const bool | cyclic |
| If true the schedule table is cyclic. More... | |
| volatile TickType | currentTick |
| Current tick of the schedule table. More... | |
| volatile ScheduleTableStatusType | currentState |
| Current state of the schedule table. More... | |
| volatile ScheduleTableType | next |
| Schedule table queued after the current one. More... | |
Detailed Description
Structure for schedule table.
Definition at line 73 of file ScheduleTableTypes.h.
Field Documentation
◆ autoStart
| const bool autoStart |
If true the schedule table will be started at startup.
Definition at line 79 of file ScheduleTableTypes.h.
◆ counter
| const CounterType counter |
Counter driving the schedule table.
Definition at line 78 of file ScheduleTableTypes.h.
◆ currentState
| volatile ScheduleTableStatusType currentState |
Current state of the schedule table.
Definition at line 83 of file ScheduleTableTypes.h.
◆ currentTick
| volatile TickType currentTick |
Current tick of the schedule table.
Definition at line 82 of file ScheduleTableTypes.h.
◆ cyclic
| const bool cyclic |
If true the schedule table is cyclic.
Definition at line 81 of file ScheduleTableTypes.h.
◆ expiryPointList
| const struct scheduleTableExpiryPoint_s* expiryPointList |
List of expiry points.
Definition at line 77 of file ScheduleTableTypes.h.
◆ finalDelay
| const TickType finalDelay |
Final delay of schedule table (applied after last expiry point.
Definition at line 74 of file ScheduleTableTypes.h.
◆ next
| volatile ScheduleTableType next |
Schedule table queued after the current one.
Definition at line 84 of file ScheduleTableTypes.h.
◆ numExpiryPoints
| const uint8_t numExpiryPoints |
Length of expiryPointList.
Definition at line 76 of file ScheduleTableTypes.h.
The documentation for this struct was generated from the following file:
- /github/workspace/AutosarOS/include/Types/ScheduleTableTypes.h
